Bourns 3296Y Series 25-Turn Through Hole Trimmer Resistor with Pin Terminations, 20kΩ ±10% 1/2W ±100ppm/°C

Description

Shaft Diameter: 2.19 mm

Orientation: Top Adjust

Mounting Type: Through Hole

Series: 3296

Termination Style: Pin

Number of Turns: 25

Temperature Coefficient: ±100ppm/°C

Length: 9.53mm

Minimum Operating Temperature: -55°C

Power Rating: 0.5W

Maximum Resistance: 20kΩ

Tolerance: ±10%

Maximum Operating Temperature: +125°C

This is 3296Y Series 25-Turn Through Hole Trimmer Resistor with Pin Terminations 20kΩ ±10% 1/2W ±100ppm/°C manufactured by Bourns. The manufacturer part number is 3296Y-1-203LF. The diameter of the shaft is 2.19 mm. The product has a top adjust orientation. The product is available in through hole configuration. The product 3296, is a highly preferred choice for users. Moreover, it has pin terminal style. Consist of 25 turns. It exhibits an excellent temperature coefficient of ±100ppm/°c. Its accurate length is 9.53mm. Whereas, the minimum operating temperature of the product is -55°c. Feature 0.5w of power rating. The product offers a maximum resistance up to 20kω. It features ±10% of tolerance value. It has a maximum operating temperature of +125°c.
