STMicroelectronics STL260N4F7

Description

Maximum Drain Source Voltage: 40 V

Mounting Type: Surface Mount

Channel Mode: Enhancement

Channel Type: N

Package Type: ECOPACK

Number of Elements per Chip: 1

Maximum Continuous Drain Current: 120 A

Pin Count: 4

FET Feature: –

HTSUS: 8541.29.0095

Vgs(th) (Max) @ Id: 4V @ 250µA

Operating Temperature: -55°C ~ 175°C (TJ)

Package / Case: 8-PowerVDFN Rds On (Max) @ Id, Vgs: 1.1mOhm @ 24A, 10V Gate Charge (Qg) (Max) @ Vgs: 72 nC @ 10 V RoHS Status: ROHS3 Compliant REACH Status: REACH Unaffected edacadModel: STL260N4F7 Models FET Type: N-Channel Drive Voltage (Max Rds On, Min Rds On): 10V edacadModelUrl: /en/models/12697739Package: Tape & Reel (TR) Drain to Source Voltage (Vdss): 40 V Vgs (Max): ±20V Moisture Sensitivity Level (MSL): 1 (Unlimited) Power Dissipation (Max): 188W (Tc) Input Capacitance (Ciss) (Max) @ Vds: 5000 pF @ 25 V standardLeadTime: 39 Weeks Mounting Type: Surface Mount Series: STripFET™ F7 Supplier Device Package: PowerFlat™ (5×6) Current – Continuous Drain (Id) @ 25°C: 120A (Tc) Technology: MOSFET (Metal Oxide) Base Product Number: STL260 ECCN: EAR99

This ismanufactured by STMicroelectronics. The manufacturer part number is STL260N4F7. It has a maximum of 40 v drain source voltage. The product is available in surface mount configuration. The product carries enhancement channel mode. The product is available in [Cannel Type] channel. The package is a sort of ecopack. It consists of 1 elements per chip. While 120 a of maximum continuous drain current. It contains 4 pins. It is assigned with possible HTSUS value of 8541.29.0095. The typical Vgs (th) (max) of the product is 4v @ 250µa. The product has -55°c ~ 175°c (tj) operating temperature range. Moreover, the product comes in 8-powervdfn. It has a maximum Rds On and voltage of 1.1mohm @ 24a, 10v. The maximum gate charge and given voltages include 72 nc @ 10 v. The product is rohs3 compliant. In addition, it is reach unaffected. It carries FET type n-channel. The drive voltage (maximum and minimum Rds On) of the product includes 10v. It is shipped in tape & reel (tr) package . The product has a 40 v drain to source voltage. The maximum Vgs rate is ±20v. Its typical moisture sensitivity level is 1 (unlimited). The product carries maximum power dissipation 188w (tc). The product’s input capacitance at maximum includes 5000 pf @ 25 v. It has a long 39 weeks standard lead time. The product stripfet™ f7, is a highly preferred choice for users. powerflat™ (5×6) is the supplier device package value. The continuous current drain at 25°C is 120a (tc). This product use mosfet (metal oxide) technology. Moreover, it corresponds to stl260, a base product number of the product. The product is designated with the ear99 code number.
