Mersen, 32M63, A2, Bolted Tag Fuse, gM, 250 V dc, 415 V ac

Description

Tag Type: Bolted

Body Diameter: 21.9mm

Application Category: gM

Current Rating: 32M63

Fuse Dimensions: 21.9 x 56.5mm

Voltage Rating: 250 V dc, 415V ac

Fixing Centres: 73mm

Fuse Size: A2

Tag Width: 9.2mm

Tag Orientation: Offset

High Rupture Capacity: No

Body Height: 56.5mm

Fuse Standard: BS 88, IEC 60269 Overall Length: 86mm

This is 32M63 A2 Bolted Tag Fuse gM 250 V dc 415 V ac manufactured by Mersen. The manufacturer part number is K226283. It has a bolted type tag . Concerning body diameter, it is 21.9mm. The product has a gm application category. The product has a current rating of 32m63. The fuse dimensions of the product is 21.9 x 56.5mm . Moreover, the product has a nominal 250 v dc, 415v ac voltage rating. It has a typical 73mm fixing centres . A fuse with a a2 size. Its tag is 9.2mm wide . Moreover, its tag orientation is offset . Moreover, it has a high rupture capacity no . Its body height is 56.5mm. The fuse complies with bs 88, iec 60269 standards. It has an overall length of 86mm.
