RF Solutions ESP-12S 3 → 3.6V WiFi Module, 802.11b/g/n

Description

Supported Protocol: 802.11b/g/n

Dimensions: 24 x 16 x 3mm

Supported Security Standards: WEP, WPA2-PSK, WPA-PSK

Height: 3mm

Width: 16mm

Length: 24mm

Supply Voltage: 3 to 3.6V

Minimum Operating Temperature: -20 °C

Maximum Operating Temperature: +85 °C

HTSUS: 8517.62.0090

RoHS Status: RoHS Compliant

Operating Temperature: -20°C ~ 85°C

Memory Size: – Package / Case: Module Current – Transmitting: 11.1mA Current – Receiving: – Modulation: 64-QAM, BPSK, CCKData Rate: 54MbpsPackage: Bag Moisture Sensitivity Level (MSL): Not Applicable RF Family/Standard: WiFi standardLeadTime: 14 Weeks Protocol: 802.11b/g/n Utilized IC / Part: – Mounting Type: Surface Mount Antenna Type: PCB Trace Series: – Serial Interfaces: ADC, I²C, PWM, SPI, UART Frequency: 2.412GHz ~ 2.484GHz Voltage – Supply: 3V ~ 3.6V Power – Output: 16dBm Sensitivity: -90dBm Base Product Number: ESP-12 ECCN: 5A002A1

This is 3 → 3.6V WiFi Module 802.11b/g/n manufactured by RF Solutions. The manufacturer part number is ESP-12S. It has 802.11b/g/n supported protocol . The given dimensions of the product include 24 x 16 x 3mm. It has a/an wep, wpa2-psk, wpa-psk supported security standards . In addition, the height is 3mm. Furthermore, the product is 16mm wide. Its accurate length is 24mm. Features 3 to 3.6v supply voltage. Whereas, the minimum operating temperature of the product is -20 °c. It has a maximum operating temperature of +85 °c. It is assigned with possible HTSUS value of 8517.62.0090. The product is rohs compliant. The product has -20°c ~ 85°c operating temperature range. Moreover, the product comes in module. It carries 11.1ma transmission current. Features 64-qam, bpsk, cck modulation. It has a maximised data speed rate of 54mbps. It is shipped in bag package . Its typical moisture sensitivity level is not applicable. The standard RF Family of the product includes wifi. It has a long 14 weeks standard lead time. The product features a 802.11b/g/n protocol. The product is available in surface mount configuration. It is a pcb trace antenna. It features adc, i²c, pwm, spi, uart serial interface. Supplied with 2.412ghz ~ 2.484ghz of frequency. It has optimum voltage supply of 3v ~ 3.6v. The product has an output power 16dbm. The sensitivity given includes -90dbm. Moreover, it corresponds to esp-12, a base product number of the product. The product is designated with the 5a002a1 code number.
